TTP111ASN
Model：TTP111ASN
Package：SSOP24
The TTP111 is a touch detector IC for the DC LED lightings with NMOS application
ƒ Operating voltage typical 5.0V ƒ
Operating current @VDD=5.0V, 25℃ no load <500uA
ƒ Higher frequency 4.8KHz PWM output. ƒ
Support two option pin to select 4 type dimmer modes.
(1). 3 steps dimmer initial OFF. OPT2=0, OPT1=1
(2). 4 steps dimmer initial OFF. OPT2=1, OPT1=0
(3). 3 steps dimmer initial ON (6%). OPT2=0, OPT1=0
(4). toggle ON / OFF initial OFF. OPT2=1, OPT1=1 ƒ
TTP111 PWM output active high control NMOS. ƒ
Two input dimmer modes: touch plate and switch ƒ
The application circuit is simple and easy. ƒ
Can use wire to connect the IC to touch plate.
LED LAMP ƒ
For PWM control input
